VOLIYA-FDS系列全自动加药系统是一种集配药、投药、自动控制功能于一体的成套设备，在众多领域发挥着重要作用。它被广泛应用于电厂的原水、锅炉给水处理，油田地面集输脱水处理系统，以及造纸、化工、给排水等各种加药系统和废水处理系统。在这些系统中，它可用于投加多种药剂，如混凝剂、磷酸盐、氨液、石灰水、缓蚀剂、阻垢剂、杀菌灭藻剂、酸、碱等，以满足不同的工艺需求。自动加药设备还被应用于电厂的循环水、炉水以及其他行业如环保、石油、化工、市政工程及供水系统等领域的除垢、除氧、混凝等工艺。

The VOLIA-FDS series of fully automatic dosing systems is a complete set of equipment integrating the functions of drug preparation, dosing and automatic control, and plays an important role in many fields. It is widely applied in the raw water and boiler feed water treatment of power plants, the surface gathering and transportation dehydration treatment system of oil fields, as well as various dosing systems and wastewater treatment systems in papermaking, chemical industry, water supply and drainage, etc. In these systems, it can be used to add a variety of chemicals, such as coagulants, phosphates, ammonia solution, lime water, corrosion inhibitors, scale inhibitors, biocides and algaecides, acids, alkalis, etc., to meet different process requirements. Automatic dosing equipment is also applied in the processes of scale removal, deaeration and coagulation in the circulating water and boiler water of power plants, as well as in other industries such as environmental protection, petroleum, chemical engineering, municipal engineering and water supply systems.

该设备以计量泵为主要投加设备，将溶药箱、搅拌器、液位计、安全阀、止回阀、压力表、过滤器、缓冲器、管路、阀门、底座、扶梯、自动监视系统、电力控制系统等按工艺流程需要组装在一个公共平台上，形成撬装式组合式单元。系统的标配件有全自动智能控制系统、计量泵、加药桶；选配件包括污垢热阻在线监测仪、水质参数在线监测仪、电导率在线控制仪、PH值在线监测仪、药剂浓度监测仪、腐蚀实时在线监测仪、电磁排污阀、流量仪。

This equipment takes the metering pump as the main dosing device, and integrates the solution tank, agitator, liquid level gauge, safety valve, check valve, pressure gauge, filter, buffer, pipeline, valve, base, ladder, automatic monitoring system, power control system, etc. on a common platform according to the process requirements, forming a skid-mounted combined unit. The standard accessories of the system include a fully automatic intelligent control system, metering pumps, and dosing buckets. Optional accessories include online dirt thermal resistance monitoring instrument, online water quality parameter monitoring instrument, online conductivity control instrument, online PH value monitoring instrument, chemical concentration monitoring instrument, real-time corrosion online monitoring instrument, electromagnetic blowdown valve, and flow meter.

工作原理Working principle

VOLIYA-FDS系列全自动加药系统依据所需药剂的浓度，在配药箱内进行药剂配置。配置过程中，搅拌器会对药剂和水进行搅拌，使它们充分混合均匀。混合好的溶液随后被投入溶液箱，再通过计量泵将溶液输送至投药点或指定系统中。该设备以计量泵为主要投加设备，将溶药箱、搅拌器、液位计、安全阀、止回阀、压力表、过滤器、缓冲器、管路、阀门、底座、扶梯、自动监视系统、电力控制系统等按工艺流程需要组装在一个公共平台上，形成撬装式组合式单元。其核心工作原理为将药剂在搅拌溶液箱溶解后，由计量泵输送至投加点，加药量可自由调节，流量调节范围为1L/h至8000L/h，压力覆盖0.1MPa至25MPa，计量精度达±1%。部分设备通过以太网技术整合数据分析模块、主控制模块等单元，实现污水处理工艺的智能控制。而且，加药装置还可根据用户不同工艺流程的要求，进行有针对性的设计，配置必要的部件，从而实现自动远程控制等功能。

The VOLYA-FDS series of fully automatic dosing systems prepare chemicals in the dosing box according to the required concentration of the chemicals. During the configuration process, the stirrer will stir the chemicals and water to ensure they are thoroughly and evenly mixed. The well-mixed solution is then put into the solution tank and transported to the dosing point or the designated system by a metering pump. This equipment takes the metering pump as the main dosing device, and integrates the solution tank, agitator, liquid level gauge, safety valve, check valve, pressure gauge, filter, buffer, pipeline, valve, base, ladder, automatic monitoring system, power control system, etc. on a common platform according to the process requirements, forming a skid-mounted combined unit. The core working principle is that the reagent is dissolved in the stirring solution tank and then transported to the dosing point by the metering pump. The dosing amount can be freely adjusted, with a flow rate adjustment range of 1L/h to 8000L/h and a pressure coverage of 0.1MPa to 25MPa. The metering accuracy reaches ±1%. Some equipment integrates data analysis modules, main control modules and other units through Ethernet technology to achieve intelligent control of the sewage treatment process. Moreover, the dosing device can also be designed in a targeted manner according to the different process requirements of users, and necessary components can be configured to achieve functions such as automatic remote control.

产品特点Product features

该设备具备完备的自动保护措施，能够保证系统稳定、安全运行，降低因设备故障导致的生产风险，为企业的正常生产提供坚实保障。

This equipment is equipped with complete automatic protection measures, which can ensure the stable and safe operation of the system, reduce production risks caused by equipment failures, and provide a solid guarantee for the normal production of enterprises.

它可以全程精确监控系统水质，并实现全自动控制排污。通过对水质的实时监测，能及时发现水质变化情况，自动进行排污操作，确保系统水质始终符合工艺要求。

It can precisely monitor the water quality of the system throughout the process and achieve fully automatic control of sewage discharge. Through real-time monitoring of water quality, changes in water quality can be detected in a timely manner, and automatic drainage operations can be carried out to ensure that the water quality of the system always meets the process requirements.

有多种配置可供选择，可针对不同的水处理用户。无论是小型企业还是大型工厂，不同的水质条件和处理要求都能找到合适的配置方案，满足多样化的市场需求。

There are multiple configurations to choose from, catering to different water treatment users. Whether it is a small enterprise or a large factory, different water quality conditions and treatment requirements can all find suitable configuration solutions to meet the diverse market demands.

另外，通过独特的预设程式，该设备可以控制加药量，既能保证加药效果，又能最大限度节省药剂用量。在达到良好处理效果的降低了企业的药剂成本支出。

In addition, through a unique preset program, this device can control the dosage of chemicals, ensuring both the effectiveness of the dosing and minimizing the amount of chemicals used to the greatest extent. The good treatment effect has been achieved, reducing the enterprise's chemical cost expenditure.

采用全自动连续式投加技术，保证各种药剂精确、及时、稳定的投加及控制。使得药剂能够均匀地分布在处理系统中，提高处理效率和效果。

Adopting fully automatic continuous dosing technology, it ensures the precise, timely and stable dosing and control of various chemicals. This enables the chemicals to be evenly distributed in the treatment system, enhancing the treatment efficiency and effectiveness.
